SY6321CSED

Part number	SY6321CSED
Vin (max) (V)	6.5
Vin (min) (V)	1.65
Iout (max) (A)	1
Output type	Adjustable
Vout (max) (V)	5.2
Vout (min) (V)	0.8
Iq (typ) (uA)	800
PSRR at 100kHz (dB)	30
Accuracy (±%)	1
Features	Precise output,Enable,Programmable soft-start,Power good,Auto-discharge,Over current protection,Thermal shutdown
Operating temperature range(°C)	-40 to 125
Package	DFN2.5×2.5-10
Functional safety category
