SY50354HZP

Part number	SY50354HZP
Pout (max) (W)	65
HV startup	YES
Operation mode	CCM/QR
Integrated FETs type	GaN
Breakdown voltage (V)	700
Ron (typ) (mΩ)	0.27
No load loss (mW)	<50
Switching frequency (min)(kHz)	25
Switching frequency (max)(kHz)	500
Features	SSR CV,Wide VCC range,GaN driver
Package	SSOP9E
Operating temperature range(°C)	-40 to 125
Functional safety category
