SY2A55105 (SA59102)

Part number	SY2A55105
Features	High precise
Direction	Bidirection
Common mode voltage (min)(V)	-0.3
Common mode voltage (max)(V)	26
Vcc max (V)	5.5
Vcc min (V)	3
Input offset (±)(max)(μV)	50
Input offset drift (±)(typ)(μV/℃)	0.1
Voltage gain (V/V)	100
Bandwidth (kHz)	28
CMRR (min)(dB)	105
Gain error (max)(%)	0.5
Iq (max)(mA)	0.1
Operating temperature range(°C)	-40 to 125
Package	SOT363
Pin count	6
