SY28481BDCD (SQ24801BDCD)
Production
Technical Documentation
| Title | Date |
|---|---|
| Automotive Solutions Q4 2025 | 2025-12-02 |
| Consumer Selection Guide Q4 2025 | 2025-12-02 |
| Industrial Designs Q4 2025 | 2025-12-02 |
| Part number | SY28481BDCD |
|---|---|
| Vin (min) (V) | 3 |
| Vin (max) (V) | 24 |
| Vabs cont. (max) (V) | 30 |
| Iout (max) (A) | 10 |
| Protection mode | OCP |
| Over current response | Circuit breaker |
| Current limit (A) | Adjustable |
| Fault response | Latch-off |
| Ron (typ) (mΩ) | 5.2 |
| Certification recognition | |
| Iq (typ) (uA) | 190 |
| Enable logic | High |
| Soft start | Adjustable |
| Features | Power good |
| Package | DFN3×3-12 |
| Operating temperature range(°C) | -40 to 125 |
| Functional safety category |
