SY28480QEQ (SQ24800QEQ)
Production
Technical Documentation
| Title | Date |
|---|---|
| Automotive Solutions Q4 2025 | 2025-12-02 |
| Consumer Selection Guide Q4 2025 | 2025-12-02 |
| Industrial Designs Q4 2025 | 2025-12-02 |
| Part number | SY28480QEQ |
|---|---|
| Vin (min) (V) | 4.5 |
| Vin (max) (V) | 18 |
| Vabs cont. (max) (V) | 20 |
| Iout (max) (A) | 50 |
| Protection mode | OCP, UVP, OTP |
| Over current response | Current limiting |
| Current limit (A) | Adjustable |
| Fault response | Auto-recovery |
| Ron (typ) (mΩ) | 0.76 |
| Certification recognition | |
| Iq (typ) (uA) | 1440 |
| Enable logic | High |
| Soft start | Adjustable |
| Features | Fault indicator, OCP alert |
| Package | QFN5×5-32 |
| Operating temperature range(°C) | -40 to 125 |
| Functional safety category |
