SY28480BQEQ (SQ24800BQEQ)

Part number	SY28480BQEQ
Vin (min) (V)	4.5
Vin (max) (V)	18
Vabs cont. (max) (V)	20
Iout (max) (A)	50
Protection mode	OCP, UVP, OTP
Over current response	Circuit breaker
Current limit (A)	Adjustable
Fault response	Latch-off
Ron (typ) (mΩ)	0.76
Certification recognition
Iq (typ) (uA)	1440
Enable logic	High
Soft start	Adjustable
Features	OCP alert
Package	QFN5×5-32
Operating temperature range(°C)	-40 to 125
Functional safety category
