SY24655 (SQ52205)

Part number	SY24655
Resolution (bit)	16
Common mode voltage (max)(V)	36
Common mode voltage (min)(V)	0
Vcc max (V)	5.5
Vcc min (V)	2.7
Input offset (±)(max)(μV)	10
Input offset drift (±)(typ)(μV/℃)	0.1
Shunt voltage range(mV)	±81.92
Gain error (max)(%)	0.15
Gain error drift (±)(max)(ppm/℃)	50
CMRR (min)(dB)	130
Channel(#)	1
Power measurement accuracy(%)	0.30
Iq (max) (μA)	370
Operating temperature range(°C)	-40 to 125
Package	VSSOP
Pin count	10
