SY23425AABT (SY5231AABT)
Production
Technical Documentation
| Title | Date |
|---|---|
| Automotive Solutions Q4 2025 | 2025-12-02 |
| Consumer Selection Guide Q4 2025 | 2025-12-02 |
| Industrial Designs Q4 2025 | 2025-12-02 |
| Part number | SY23425AABT |
|---|---|
| Topology | Flyback |
| Integrated FETs(Yes/No) | NO |
| Integrated FETs type | |
| Breakdown voltage (V) | 200V |
| Ron (typ) (mΩ) | |
| ZVS function | NO |
| Operation mode | CCM/QR/DCM |
| Dual supply channel | YES |
| Features | Gate clamped before VDD on,DSEN voltage falling slope rate detection,DSEN voltage blanking time detection |
| Package | SOT23-6 |
| Operating temperature range(°C) | -40 to 125 |
| Functional safety category |
