SY23413NFAP (SY50213NFAP)
Production
Technical Documentation
| Title | Date |
|---|---|
| Automotive Solutions Q4 2025 | 2025-12-02 |
| Consumer Selection Guide Q4 2025 | 2025-12-02 |
| Industrial Designs Q4 2025 | 2025-12-02 |
| Part number | SY23413NFAP |
|---|---|
| Pout (max) (W) | 12 |
| HV startup | NO |
| Operation mode | QR |
| Integrated FETs type | MOS |
| Breakdown voltage (V) | 650 |
| Ron (typ) (mΩ) | 4.4 |
| No load loss (mW) | <75 |
| Switching frequency (min)(kHz) | 0.5 |
| Switching frequency (max)(kHz) | 125 |
| Features | PSR CC/CV,Cable compensation |
| Package | SO8 |
| Operating temperature range(°C) | -40 to 125 |
| Functional safety category |
