SY23329FIB (SY50329FIB)
Production
Technical Documentation
| Title | Date |
|---|---|
| Automotive Solutions Q4 2025 | 2025-12-02 |
| Consumer Selection Guide Q4 2025 | 2025-12-02 |
| Industrial Designs Q4 2025 | 2025-12-02 |
| Part number | SY23329FIB |
|---|---|
| Pout (max) (W) | 30 |
| HV startup | YES |
| Operation mode | CCM/DCM |
| Integrated FETs type | MOS |
| Breakdown voltage (V) | 700 |
| Ron (typ) (mΩ) | 1.9 |
| No load loss (mW) | <50 |
| Switching frequency (min)(kHz) | 23.5 |
| Switching frequency (max)(kHz) | 100 |
| Features | SSR CV,Pseudo fixed frequency |
| Package | DIP7 |
| Operating temperature range(°C) | -40 to 125 |
| Functional safety category |
