SY22847BFAC (SY50271BFAC)

Production
    Part numberSY22847BFAC
    Pout (max) (W)4.3
    HV startupYES
    Iout (max) (A)0.36
    Vout (typ)(V)12V
    Breakdown voltage (V)650
    Ron (typ) (mΩ)9
    Switching frequency (min)(kHz)37
    Switching frequency (max)(kHz)40
    Operation modeCCM/DCM
    No load loss (mW)<50
    FeaturesMulti-off-time control
    PackageSO8
    Operating temperature range(°C)-40 to 125
    Functional safety category
