SY20831FAAT (SY86201FAAT)
Production
Technical Documentation
| Title | Date |
|---|---|
| Automotive Solutions Q4 2025 | 2025-12-02 |
| Consumer Selection Guide Q4 2025 | 2025-12-02 |
| Industrial Designs Q4 2025 | 2025-12-02 |
| Part number | SY20831FAAT |
|---|---|
| Channel(#) | 1 |
| Vin (min) (V) | 2.5 |
| Vin (max) (V) | 5.5 |
| Iout (max) (A) | 1.4 |
| Iq (typ) (uA) | 45 |
| Protection mode | Auto-recovery OCP,Auto-recovery OTP |
| Current limit (A) | Fixed |
| Ron (typ) (mΩ) | 65 |
| Enable logic | High |
| Output discharge | YES |
| Certification recognition | UL2367,IEC62368 |
| Features | Reverse blocking, OCP alert |
| Package | SOT23-5 |
| Operating temperature range(°C) | -40 to 125 |
| Functional safety category |
