SQ52206

Part number	SQ52206
Resolution (bit)	16
Common mode voltage (max)(V)	120
Common mode voltage (min)(V)	0
Vcc max (V)	5.5
Vcc min (V)	2.7
Input offset (±)(max)(μV)	5
Input offset drift (±)(typ)(μV/℃)	0.02
Shunt voltage range(mV)	±163.84/ ±81.92/ ±40.96
Gain error (max)(%)	0.14
Gain error drift (±)(max)(ppm/℃)	40
CMRR (min)(dB)	144
Channel(#)	1
Power measurement accuracy(%)	0.80
Iq (max) (μA)	1300
Operating temperature range(°C)	-40 to 125
Package	VSSOP
Pin count	10
