| Part number | SQ51225QJQ |
|---|---|
| Rail (#) | 2 |
| Phase | N+M≤5 |
| Vcc (typ) (V) | 5 |
| Switching frequency (max)(kHz) | 300 |
| Switching frequency (min)(kHz) | 2000 |
| Interface | PMBus,AVSBus |
| Features | COT |
| Package | QFN7×7-48 |
| Operating temperature range(°C) | -40 to 125 |
| Functional safety category |
