| Part number | SQ33604AFBP |
|---|
| Channel(#) | 1 |
|---|
| Vin (min) (V) | 8.5 |
|---|
| Vin (max) (V) | 75 |
|---|
| Topology | PSR/SSR flyback |
|---|
| Switching frequency (min)(kHz) | 100 |
|---|
| Switching frequency (max)(kHz) | 500 |
|---|
| Vout (min) (V) | Programmable |
|---|
| Vout2 (min)(V) | |
|---|
| Vout (max) (V) | Programmable |
|---|
| Vout2 (max )(V) | |
|---|
| Vref accuracy (±%) | 1.5 |
|---|
| Vout accuracy(±%) | |
|---|
| Control mode | Peak current mode |
|---|
| Duty cycle (max)(%) | 83 |
|---|
| Operation mode | PWM/PFM |
|---|
| Iq (typ) (uA) | 1250 |
|---|
| Features | HV startup,PSR/SSR,Auto-recovery input UVP,Auto-recovery OCP,Auto-recovery SCP,Auto-recovery OVP,Auto-recovery OTP |
|---|
| Package | MSOP10 |
|---|
| Operating temperature range(°C) | -40 to 125 |
|---|
| Functional safety category | |
|---|
