SA59202DAA

Part number	SA59202DAA
Resolution (bit)	12
Common mode voltage (max)(V)	25
Common mode voltage (min)(V)	3.6
Vcc max (V)	25
Vcc min (V)	3.6
Input offset (±)(max)(μV)	312.5
Input offset drift (±)(typ)(μV/℃)
Shunt voltage range(mV)	±50
Gain error (max)(%)	1
Gain error drift (±)(max)(ppm/℃)
CMRR (min)(dB)
Channel(#)	1
Power measurement accuracy(%)
Iq (max) (μA)	600
Operating temperature range(°C)	-40 to 125
Package	DFN
Pin count	8
