| Part number | SA52122BHHP |
|---|
| Vin (max) (V) | 32 |
|---|
| Vin (min) (V) | 4.5 |
|---|
| Number of half bridges | 12 |
|---|
| RDS(on) (HS + LS) (mΩ) | 1500 |
|---|
| Peak output current (A) | 1.5 |
|---|
| Sleep current (µA) | 1 |
|---|
| Integrated FETs(Yes/No) | Yes |
|---|
| Control interface | SPI |
|---|
| Features | Low power sleep mode, Support paralleled output mode, Support daisy chain functionality,Spread spectrum to optimize EMC performence, OVP, OCP, SCP, OLD, Undervoltage lockout |
|---|
| Operating temperature range(°C) | -40 to 125 |
|---|
| Package | TSSOP24 |
|---|
| Functional safety category | Functional safety capable |
|---|
